6253 DC Voltage Current Source/Monitor Operation Manual
1.4.4 Power Cable
1-9
1.4.4 Power Cable
CAUTION:
1. Use a power cable that conforms to the power outlet voltage and type. However, for use
outside of Japan, use only a power cable approved for the respective country.
2. To prevent electric shock, connect the power cable to an outlet with a ground terminal. If an
extension cable without a ground terminal is used, the protective ground feature will be
rendered ineffective.
3. Be sure to set the POWER switch on the front panel to OFF before connecting the power
cable.
Figure 1-5 Power cable
Into AC power outline
Ground pin
3-pin power cable
