A.2 Error Message List
If an error occurs when using the 6253, an error code and a message appear on the screen. The contents are
explained in the following:
Table A-2 Error Message List (1 of 3)
Error
code
Message Description
001 ROM Chk SUM ROM check SUM error
004 RAM Rd/Wt RAM read/write error
005 Analog Comm Analog section communication error
012 CAL data SUM CAL data SUM error
013 Param SUM Parameter SUM error
101 AD1 Ratio 1-2 AD1 operation IR1/IR2 ratio test error
102 AD1 Ratio 2-3 AD1 operation IR2/IR3 ratio test error
103 AD1 Ratio 3-4 AD1 operation IR3/IR4 ratio test error
104 AD1 Ratio 4-5 AD1 operation IR4/IR5 ratio test error
105 AD1 Ratio 5-6 AD1 operation IR5/IR6 ratio test error
111 ADRST Sig Analog section RST line test error
112 ADTRG Sig Analog section TRIG line test error
121 AD2 Ratio 1-2 AD2 operation IR1/IR2 ratio test error
122 AD2 Ratio 2-3 AD2 operation IR2/IR3 ratio test error
123 AD2 Ratio 3-4 AD2 operation IR3/IR4 ratio test error
124 AD2 Ratio 4-5 AD2 operation IR4/IR5 ratio test error
125 AD2 Ratio 5-6 AD2 operation IR5/IR6 ratio test error
151 AD1 Zero AD1 operation ZERO test error
152 AD2 Zero AD2 operation ZERO test error
201 VSVM 300mV Zero VSVM 300 mV ZERO test error
202 VSVM 300mV +FS VSVM 300 mV +FS test error
203 VSVM 300mV -FS VSVM 300 mV –FS test error
204 VSVM 3V Zero VSVM 3 V ZERO test error
205 VSVM 3V +FS VSVM 3 V +FS test error
206 VSVM 3V -FS VSVM 3 V –FS test error
207 VSVM 10V Zero VSVM 10 V ZERO test error
208 VSVM 10V +FS VSVM 10 V +FS test error
209 VSVM 10V -FS VSVM 10 V –FS test error
210 VSVM 30V Zero VSVM 30 V ZERO test error
211 VSVM 30V +FS VSVM 30 V +FS test error
212 VSVM 30V -FS VSVM 30 V –FS test error
213 VSVM 100V Zero VSVM 100 V ZERO test error
