ADCMT 6253 - Integration Time and Processing Time

6253 DC Voltage Current Source/Monitor Operation Manual
4.2.8 Source and Measurement Timing
4-53
4.2.8.4 Integration Time and Measurement Time
The measurement time (Tm) is calculated from the integration time (Tit), measurement data processing
time (Tk) and internal processing time (Tsys) according to the following formula:
Tm = Tit + Tk + Tsys
The integration time (Tit) can be selected between 5 s and 1000 ms.
The measurement data processing time (Tk) details are shown in the Table 4-11.
The internal processing time (Tsys) is determined depending on the Memory Store mode as below.
*1: All measurement data are processed when sweep ends.
Source mode Memory Store Tsys (ms)
DC
Pulse
OFF Approx. 2
Normal Approx. 2
Burst Approx. 2
DC sweep
Pulse sweep
OFF Approx. 2
Normal Approx. 2
Burst Approx. 2 *1
Table 4-11 Integration Time and Processing Time
Integration
time
Tit (ms)
Tk (ms)
Tit + Tk (ms)
50 Hz 60 Hz 50 Hz 60 Hz
5 s 0.005 0.013 0.018
10 s 0.01 0.024 0.034
100 s 0.1 0.08 0.18
500 s 0.5 0.04 0.54
1 ms 1 0.04 1.04
10 ms 10 0.04 10.04
1 PLC 20 16.666 0.04 20.04 16.706
2 PLC 40 33.333 0.04 40.04 33.373
200 ms 200 0.04 200.04
Other 0.1 to 1000 0.04 Tit + 0.04
