ADCMT 6253 - Calibration Procedure

6253 DC Voltage Current Source/Monitor Operation Manual
7.5 Calibration Procedure
7-9
Figure 7-5 Calibration Procedure (4)
[Calibration mode
setting]
[Range setting]
IS mode
IL-Hi mode
IL-Lo mode
Enters the DMM data input mode.
DMM data
acquisition
DMM data
acquisition
DMM data
acquisition
DMM data input
*Out-of-range setting results in a parameter error.
DMM data input
*Out-of-range setting results in a parameter error.
XD DMM data
XD DMM data
Within tolerance
range?
DMM data
acquisition
Calibration result data
save and display
Calibration result data
save and display
Checks the calibration result.
Current source/
limit calibration
(3μA to 300 mA range)
