ADCMT 6253 - Self-Test Items

6253 DC Voltage Current Source/Monitor Operation Manual
4.2.15 Self-Test
4-74
4.2.15 Self-Test
The 6253 can self-test internal operations by turning on the power, executing the remote command, or
manual operation.
1. The self-test items and output results are shown below.
Table 4-18 Self-Test Items (1 of 3)
Error code Description
Execution method TER register (*1)
Power ON *TST? Register Data
001 ROM check SUM 
--004 RAM read/write 
005 Analog section communication 
012 CAL data SUM 
a
2
013 Parameter SUM  4
501 Calibration data lost  16
502 Saved data lost  32
503 Saved parameter data lost  64
101 AD 1 operation IR1/IR2 ratio 
b
1
102 AD 1 operation IR2/IR3 ratio  2
103 AD 1 operation IR3/IR4 ratio  4
104 AD 1 operation IR4/IR5 ratio  8
105 AD 1 operation IR5/IR6 ratio  16
111 Analog section RST line test  32
112 Analog section TRIG line test  64
121 AD 2 operation IR1/IR2 ratio  128
122 AD 2 operation IR2/IR3 ratio  256
123 AD 2 operation IR3/IR4 ratio  512
124 AD 2 operation IR4/IR5 ratio  1024
125 AD 2 operation IR5/IR6 ratio  2048
151 AD 1 operation ZERO  4096
152 AD 2 operation ZERO  8192
