ADCMT 6253 - Calibration Procedure

6253 DC Voltage Current Source/Monitor Operation Manual
7.5 Calibration Procedure
7-11
Figure 7-7 Calibration Procedure (6)
[Range setting]
Enters the DMM data input mode.
DMM data
acquisition
DMM data
acquisition
IM mode
Within tolerance
range?
DMM data input
XD DMM data
Measurement data
read out
DMM data input
XD DMM data
Measurement data
read out
Calibration result data
save and display
Calibration result data
save and display
Current measurement
calibration
(3 μA to 300 mA range)
