4.3.2 Difference in Source Period Parameter
4-78
4.3.2 Difference in Source Period Parameter
Note that the period parameter Tp is defined differently from the 6243/6244 as below.
4.3.3 Precautions for Synchronous Operation
While the 6243/6244 has no delay time from external trigger input to measurement start, the 6253 has the
delay time Tsync.
Thus, when operating the 6243/6244 and the 6253 in synchronization, consider the delay time Tsync in
reference to Section 4.2.11.1, “Synchronous Operation.”
Source mode 6253 6243/6244
Pulse
DC sweep
Pulse sweep
