6253 DC Voltage Current Source/Monitor Operation Manual
5.7.2 Compatible Mode
5-28
2. Mantissa part and exponent part
The exponent columns below show exponents when scaling calculation is not performed.
*1: Data does not exist when the measurement buffer memory data is read out.
Measurement function
Unit display
Decimal point and unit symbol form
Mantissa part Exponent part
DC voltage
measurement
Measurement
range
300 mV ddd.ddd E-3
3 V d.ddddd E+0
10 V dd.dddd E+0
30 V dd.dddd E+0
100 V ddd.ddd E+0
DC current
measurement
3 A d.ddddd E-6
30 A dd.dddd E-6
300 A ddd.ddd E-6
3 mA d.ddddd E-3
30 mA dd.dddd E-3
300 mA ddd.ddd E-3
2 A d.ddddd E+0
Measurement function Mantissa part Exponent part
Range over +999.999 E+9
Scaling error E+2
TOTAL error E+1
No data exists at recall. *1 +888.888 E+8
