6253 DC Voltage Current Source/Monitor Operation Manual
2.1.1 Front Panel
2-2
3. Display Displays source values, measured values and other information.
For more information, refer to 2.2, “Display.”
4. Soft Keys The soft keys are used to select the displayed items on the lower
side of the screen.
Mode Selecting the source mode
Source Source condition setting
Measure Measurement condition setting
Limit Limit value setting
Time Time setting screen display
For more information on the soft keys, refer to Section 2.3, “Soft
Keys.”
5. Other keys and rotary knob
• Rotary knob Increases or decreases the digit at the cursor position, and selects
units or parameters. In the direct input mode, it selects units. On
the MENU screen, it selects parameters vertically.
• Right and left key Move the cursor position at numerical input.
• MENU key Displays the parameter group setting screen (MENU screen) and
the key is lit. Pressing the key again returns to the home screen.
• SHIFT key When the key is lit, blue colored characters on the panel are
enabled.
• ENTER key Fixes selected parameters. In the direct input mode, the key is lit.
• EXIT key (LOCAL) Cancels selected parameters or returns to the upper level in the
MENU hierarchy.
In the remote status, it switches to the local status.
• TRIG key In the HOLD trigger mode, the key triggers measurement and
pulse generation for the DC source or pulse source mode, or
triggers step generation for the sweep source mode. In the AUTO
trigger mode, it works as start key for sweep source. The key is lit
during sweep source.
• HOLD key Switches the trigger mode between AUTO and HOLD.
Turns ON when the trigger mode is set to HOLD.
• DATA ENTRY keys Numerical input keys
(0 to 9, ., +/-) Pressing any numerical input key switches to the direct input
mode. The ENTER key goes ON at this time.
Press the ENTER key to fix the input.
• OPR key Switch between Operate (output relay ON) and Suspend*. The
key is lit in the Operate status.
* In the Suspend status, the suspend voltage is output instead of
turning OFF the output relays. The key blinks.
WARNING: Beware of electrical shock! In the Operate
status (output relay ON), hazardous voltage
may occur depending on the settings.
