6253 DC Voltage Current Source/Monitor Operation Manual
2.1.2 Rear Panel
2-4
6. INTER LOCK / OPERATE IN/OUT
Refer to Section 4.2.10, “External Control Signals.”
7. TRIGGER IN Refer to Section 4.2.10, “External Control Signals.”
8. SYNC OUT Refer to Section 4.2.10, “External Control Signals.”
9. AC power connector Connects to an AC power output via the supplied power cable.
10. Voltage selector and fuse holder Used to select the voltage manually to match the AC power
supply.
A fuse is contained inside.
CAUTION: Use an appropriate fuse. Refer to Section
1.4.2, “Power Specification.”
11. Rear output terminal Refer to Section 4.1.1, “Output Terminals (Front and Rear Output
Terminals).”
CAUTION: To prevent damage to the 6253, do not apply a
voltage or current that exceeds the specified
range.
