6253 DC Voltage Current Source/Monitor Operation Manual
2.2 Display
2-6
6. MeasRng Indicates the measurement range: AUTO or FIX.
7. SrcRng Indicates the source range.
Shows whether it is AUTO or FIX when the sweep mode is selected.
8. Remote sensing setting Indicates 2 W (2-wire connection) or 4 W (4-wire connection).
9. Limit (compliance) values Indicates HL (high limit value) and LL (low limit value).
When a limit value is detected, ▲ or ▼ turns ON.
10. Source mode Indicates the source mode: DC, pulse, DC sweep or pulse sweep.
11. Comparator calculation indicators
Any of these turns ON depending on the comparator calculation result
of a measured value when the comparator calculation is ON.
12. Other annotations
• AZ: Turns On when the Auto Zero function is ON.
• NULL: Turns ON when the NULL calculation is ON.
• MATH: Turns ON when the scaling calculation is ON.
• CMP: Turns ON when the comparator calculation is ON.
• SLOW/FAST/SR: Output response. When the slew rate is set to
ON, “SR” is displayed.
• MAX: Turns ON when the Max/Min calculation is ON.
• ST: Turns ON when the measurement data memory is ON.
• OSC: Turns ON when oscillation is detected.
• : Turns ON when high voltage is detected.
• HiZ/LoZ: Impedance in the Suspend status.
• HL (high limit value) and LL (low limit value):
Turns ON when the measured value reaches the limit values.
• RMT: Turns ON in the remote control status.
• ERR: Turns ON when there are any error logs. When any of these
errors is fatal, the indicator is lit in red. Otherwise, it is lit in blue.
