2D-LC User Guide 105
5 2D-LC Data Acquisition in MassHunter Workstation 11
Start the Data Acquisition Software
You do almost all of your work within the different windows of this main
window. These windows provide tools to do the following:
• Set up acquisition methods
• Run samples interactively or automatically
• Monitor instrument status and monitor runs
Figure 50 Overview of windows, that are available in MassHunter Workstation Data
Acquisition (to switch to different windows, click options under tabs)
Actuals
Spectrum Plot
Chromatogram Plot
Instrument Status
Sample Run
Tabs
For further help, see Agilent 6200 Series TOF and 6500 Series Q-TOF LC/MS Quick
Start Guide.
