2D-LC User Guide 57
4Installation
Hardware Installation
Interface
Valve drive G1170A 1290 Infinity Valve Drive
2D-LC Valve
G4236A 2D-LC valve kit, Standard Contains the 2D-LC valve
head
G4243A 2D-LC valve kit, ASM Contains the 2D-LC valve
head with Active Solvent
Modulation (ASM)
functionality
MHC Valves
G4236A#007
G4243A#007
Multiple Heart-Cutting Kit Contains two MHC valve
heads
G4242A 2D-LC Multiple Heart-Cutting Upgrade Kit Kit to upgrade MHC valves
to an existing 2D-LC
system
Pressure
Relief Kit
(PRK)
G4236-60010 Pressure Relief Kit
Mandatory if a
1
D detector
is used. The kit prevents
pressure pulses and
protects detector flow
cells!
Table 5 Overview of recommended hardware configurations
Function Functional
Element
Part Number Module Comment
