Agilent Technologies 1290 Infinity II 2D-LC User Manual

2D-LC User Guide 69
4Installation
Hardware Installation
Port Number of
Capillary
Connection L x ID [mm] P/N Description
1 6a transfer capillary to MHC Valve (OUT), deck
A
170 x 0.12 5500-1270 Capillary ST 0.12x170 S/M
2 11 waste line self-cut x 0.7 0890-1713 Tubing-flexible 0.8/1.61mm
PTFE WT (delivered with UV
detector)
35
from pressure release kit; from
1
D column,
1
D detector
105 x 0.17
500 x 0.12
5500-1240
5500-1157
Capillary ST 0.17x105 SL/SL
Capillary ST 0.12x500 SL/S
4 6a transfer capillary to MHC Valve (IN), deck B 170 x 0.12 5500-1270 Capillary ST 0.12x170 S/M
5 6a transfer capillary to MHC Valve (OUT), deck
B
170 x 0.12 5500-1270 Capillary ST 0.12x170 S/M
67
to
2
D column
400 x 0.12 5500-1251 Capillary ST 0.12x400 SL/SL
79
from
2
D pump
280 x 0.17 5067-4608 Capillary ST 0.17x280 SX/S
8 6a transfer capillary to MHC Valve (IN), deck A 170 x 0.12 5500-1270 Capillary ST 0.12x170 S/M
