Agilent 4150 TapeStation System Manual 135
Maintenance
9
Electrode Cartridge
Exchange the Electrode Cartridge
Beyond the descriptions in this user guide you will also find a detailed and
animated description within the Agilent Information Center (see “Agilent
Information Center” on page 60).
1 During a preventive maintenance service the Electrode Cartridge is
exchanged. For details, see “Electrode Cartridge” on page 130.
2 Prepare the instrument by navigating to Settings‚ Maintenance, and Change
Electrode Cartridge. Follow further onscreen instructions.
3 Open the lid.
Wrong position of the ScreenTape nest
Instrument or cartridge damage can occur
➔ Use the TapeStation Controller software to prepare the Electrode Cartridge
exchange procedure.
➔ Remove the Electrode Cartridge only when prompted by a software dialog.
