Installing the controller
17
Installing the controller
The G1512A controller provides power and the communication interface for
18593A/B or G1513A injectors and for the 18596A or 18596B/C tray.
There are 11 connectors and two sets of switches for defining the
communication type.
Figure 12. G1512A controller and communications module
On/off button
Fault LED
Serial number
AC power receptacle
Configuration switches
Injector connectors
