Setting Up
Installing the controller
19
Setting the configuration switches
There are 16 switches on the back of the controller. Figure 14 and Figure 15
show the switches and settings for five common types of communications.
When you are using ChemStation software, you must set the GPIB address
switches to a unique address. The address for the first sampler is usually set to
“8.” For a complete list of address switches, see Table 3.
Configuration switch definitions
The following tables describe the configuration switches and their settings.
Table 1. Left-hand Switch Settings
Table 2. Right-hand Switch Settings
Switch Description Possible Values
MM Communication mode type 00—INET, standalone
10—3365 ChemStation, MS ChemStation
(Rev 3.65 and lower)
11—ChemStation, MS ChemStation
(Rev 3.71 and higher)
01—Asynchronous standalone
PP The bar code reader position 00—Front
01—Back
10—Right
11—Left
H RS-232-C host handshake 0—XON/XOFF
1—RTS/CTS
BB RS-232-C host baud rate 00—2400
01—9600
10—19.2 K
11—38.4 K
Switch Description Possible Values
LF Controller termination
message
0—Line feed only
1—Carriage return and line feed
16,8,4,2,1 GPIB address of controller 00000=0, 00001=1, 00010=2, 00011=3, etc.
(see Figure 14)
