168 Chapter3
Softkey Menus
Menu Trees
Figure 3-3 AUX CTRL (1 of 3) Key Menu Tree
* The TRACKING GENRATOR menu shown here is for spectrum analyzers without
Option 002 installed. See AUX CTRL menu 3 of 3 for an 8560E/EC with Option 002
installed.
INTERNAL MIXER is not shown for an 8560E/EC with Option 002 installed. For an
8560E/EC without Option 002, only the INTERNAL MIXER softkey is available (the
softkeys accessed by INTERNAL MIXER are not available).
EXTERNAL MIXER is not shown for an 8560E/EC with Option 002 installed and is
non-functional for Option 327.
† Signal identification functions are only available in non-preselected external
mixing mode, with firmware revisions ≤920528, or with Option 008 installed.
‡ This key changes to MARKER DELTA if the marker delta function is active.
§ This key changes to V/GHz .25 .50 for the Agilent 8564E/EC and Agilent 8565E/EC.
|| This key changes to .25V/GHz for the Agilent 8564E/EC and Agilent 8565E/EC.
