400 Chapter7
Language Reference
ACPRSLTS Adjacent Channel Power Measurement Results
ACPRSLTS Adjacent Channel Power
Measurement Results
Syntax
Figure 7-32 ACPRSLTS Syntax
Description
The ACPRSLTS command returns an array of power data resulting
from an adjacent channel power measurement of an RF signal. The size
of the array is determined by the number of alternate channel pairs
selected by the ACPALTCH command. (The default is 0.)
Power measurements and calculations are made for the selected
channels. Different measurement methods (that is, ANALOG, 2BW)
provide different power measurements. These power ratios are
described below:
ACP Ratio It is a measure of the channel power that is done as a
continuous integration.
Random Power It is a measure of the power (usually noise-like) that
exists between the leading and falling edge transients
of a burst signal.
Impulsive Power It is the peak power of the leading or falling edge
(whichever is higher) of a burst signal.
Weighted Power It is a summed combination of the random power and
impulsive power.
Average Power It is a measure of all the power in the pulse of a burst
signal. This value is only available if the burst power
method is selected.
