324 Chapter5
Programming
Creating Screen Titles
Creating Screen Titles
Screen titles allow you to label instrument data as shown in Figure
5-11. They can help identify on-screen data or data that you want to
store or print. There are commands to create titles remotely and several
methods can be used to make titles. These include using no format, or
using A-block or I-block format. Each method is described below.
Note also that the first 16 characters of a title become the label for a
stored instrument state or stored trace. The label replaces the register
number of the state or trace that usually appears on the spectrum
analyzer menu. If you save or recall states or traces remotely, be sure to
use the register number and not this label.
Figure 5-11 Screen Titles Appear in the Upper-Right Corner of the
Graticule
