Chapter 3 177
Softkey Menus
Menu Trees
Figure 3-17 MKR-> Key Menu
Figure 3-18 MODULE Key Menus
NOTE The Agilent 8562E/TAM Interface Software is required when using the
TAM with the Agilent 8562E/EC spectrum analyzer.
* MODULE accesses these additional softkeys if the Agilent 85620A mass
memory module is attached to the spectrum analyzer. See the Agilent 85620A
documentation for more information about these softkeys.
† MODULE accesses these additional softkeys if the Agilent 85629B test and
adjustment module (TAM) is attached to the spectrum analyzer. See the
Agilent 85629B documentationfor more information about these softkeys. The
Agilent 85629B is not compatible with the Agilent 8564E/EC or Agilent
8565E/EC.
