Chapter 3 169
Softkey Menus
Menu Trees
Figure 3-4 AUX CTRL (2 of 3) Key Menu Tree
* This key is not shown for an 8560E/EC with Option 002 installed and is
non-functional for Option 327.
† This signal identification function is only available with firmware revisions
≤920528 or with Option 008 installed.
‡ This key is displayed only if unpreselected external mixing is selected (EXT
MXR PRE UNPR is set to
UNPR), and is not displayed if external mixing is set
to PRE.
§ This key is displayed only if preselected external mixing is selected (EXT MXR
PRE UNPR is set to
PRE).
||
This key changes to MARKER DELTA if the marker delta function is active.
To Next Page
