398
Chapter
7
Language Reference
A
CPMST
A
TE Adjacent Channel Po
wer Measurement State
P
arameters
CURR (current), DFL
T (default)
Query Response
Figure 7-29
ACPMST
A
TE Query Response
Example
10
OUTPUT
718;"ACPMSTATE
CURR;"
