374 Chapter7
Language Reference
Syntax Diagram Conventions
In the syntax diagrams, characters and secondary keywords are shown
within circles or ovals. Characters and secondary keywords must be
entered exactly as shown.
Table 7-2 Characters and Secondary Keywords (Reserved Words)
Element Description
A ampere (unit); A-block data format; external mixer frequency band
AC alternating current (coupling)
ALL all (marker off, plot screen)
AM amplitude modulation (DEMOD)
ANNT annotation
AUTO automatic operation
B 8-bit byte output format
CURR current (IF adjustment)
D external mixer frequency band
DB relative decibel (unit)
DBM absolute decibel milliwatt (unit)
DBMV absolute decibel millivolt (unit)
DBUV absolute decibel microvolt (unit)
DC direct current (coupling)
DM absolute decibel milliwatt (unit)
DN decrement the parameter
DSP display
E external mixer frequency band
EDGE trigger edge
EP enable parameter for front panel operator entry (see note below)
EXT external (reference, mixer mode)
F external mixer frequency band
FAV frequency analog voltage (0.5 V/GHz)
FAVA frequency analog voltage attenuated (0.25 V/GHz)
FLATTOP FFT window format
FM frequency modulation (DEMOD)
FREE free run
FULL full band span width
G external mixer frequency band
GHZ gigahertz (unit)
GRT graticule
GZ gigahertz (unit)
HANNING FFT window format
HARM harmonic number (frequency diagnostic)
HI highest
HZ hertz
I I-block data format
