Agilent Technologies 8563E User Manual

Chapter 7 497
Language Reference
IP Instrument Preset
Example
10 OUTPUT 718;"IP;SNGLS;"
20 END
SQUELCH OFF
SQUELCH LEVEL −120 dBm
SWEEP TIME 60 ms, AUTO (8560E/EC) 200 ms, AUTO
(Agilent 8561E/EC) 264 ms, AUTO (Agilent
8562E/EC) 530 ms, AUTO (Agilent 8563E/EC)
800 ms, AUTO (Agilent 8564E/EC) 1 s, AUTO
(Agilent 8565E/EC)
THRESHOLD −90 dBm, OFF
TRACE A CLEAR-WRITE
TRACE B BLANK
TRACE-DATA FORMAT P
TRIGGER MODE CONTINUOUS
TRIGGER POLARITY Positive
TRIGGER SOURCE FREE-RUN
UNITS dBm, AUTO
VERTICAL SCALE 10 dB per DIV
VBW to RBW RATIO 1
VIDEO BW 1 MHz, AUTO
VIDEO AVERAGE 100, OFF
VIDEO TRIG LEVEL 0 dBm
Table 7-7 8560 E-Series and EC-Series Preset States
Function State
