Agilent Technologies 8563E User Manual

Chapter 7 581
Language Reference
RL Reference/Range Level
Table 7-8 Frequency Ranges and Minimum Reference Level (0 dB Input
Attenuation)
Minimum Reference Level
Band Log Scale Linear Scale
8560E/EC:
30 Hz to 2.9 GHz −120.0 dBm 2.2 µV
Agilent 8561E/EC:
30 Hz to 2.9 GHz −120.0 dBm 2.2 µV
2.9 GHz to 6.5 GHz −120.0 dBm 2.2 µV
Agilent 8562E/EC:
30 Hz to 2.9 GHz −120.0 dBm 2.2 µV
2.9 GHz to 6.46 GHz −120.0 dBm 2.2 µV
6.76 GHz to 13.2 GHz −120.0 dBm 2.2 µV
Agilent 8563E/EC:
30 Hz to 2.9 GHz −120.0 dBm 2.2 µV
2.9 GHz to 6.46 GHz −120.0 dBm 2.2 µV
6.46 GHz to 13.2 GHz −120.0 dBm 2.2 µV
13.2 GHz to 26.5 GHz −120.0 dBm 2.2 µV
Agilent 8564E/EC:
30 Hz to 2.9 GHz −120.0 dBm 2.2 µV
2.9 GHz to 6.46 GHz −120.0 dBm 2.2 µV
6.46 GHz to 13.2 GHz −120.0 dBm 2.2 µV
13.2 GHz to 26.8 GHz −120.0 dBm 2.2 µV
26.8 GHz to 31.15 GHz −120.0 dBm 3.98 µV
31.15 GHz to 40 GHz −115.0 dBm 3.98 µV
Agilent 8565E/EC:
30 Hz to 2.9 GHz −120.0 dBm 2.2 µV
2.9 GHz to 6.46 GHz −120.0 dBm 2.2 µV
6.46 GHz to 13.2 GHz −120.0 dBm 2.2 µV
13.2 GHz to 26.8 GHz −120.0 dBm 2.2 µV
26.8 GHz to 31.15 GHz −120.0 dBm 2.2 µV
31.15 GHz to 40 GHz −115.0 dBm 3.98 µV
40 GHz to 50 GHz −115.0 dBm 3.98 µV
