Agilent X-Series Signal Generators User’s Guide 185
Basic Digital Operation (Option 653/655/656/657)
Clipping a Waveform
Clipping a Waveform
Digitally modulated signals with high power peaks can cause intermodulation distortion, resulting in
spectral regrowth that can interfere with signals in adjacent frequency bands. The clipping function
enables you to reduce high power peaks by clipping the I and Q data to a selected percentage of its
highest peak, thereby reducing spectral regrowth.
• How Power Peaks Develop on page 186
• How Peaks Cause Spectral Regrowth on page 188
• How Clipping Reduces Peak–to–Average Power on page 189
• Configuring Circular Clipping on page 192
• Configuring Rectangular Clipping on page 193
Figure 8-8 Clipping Softkeys
Mode > Dual ARB > More
Available only when
clipping type = |I|, |Q|
For details on each key, use key help
as described on page 44.
To Next Page
