Agilent X-Series Signal Generators User’s Guide 327
Custom Digital Modulation (Option 431)
Creating and Using Bit Files
Figure 13-11 Entering Bit Values
Renaming and Saving a User File
In this example, you learn how to store a user file. If you have not created a user file, complete the
steps in the previous section, “Creating a User File” on page 325.
1. Press More (1 of 2) > Rename > Editing Keys > Clear Text.
2. Enter a file name (for example, USER1) using the alpha keys and the numeric keypad.
3. Press Enter.
The user file has now been renamed and stored to the Bit memory catalog with the name USER1.
Enter these bit values Cursor Position Indicator Hexadecimal Data
