Agilent Technologies X Series User Manual

Agilent X-Series Signal Generators User’s Guide 339
Custom Digital Modulation (Option 431)
Using the Arbitrary Waveform Generator
Creating a Custom Digital Modulation State
In this procedure, you learn how to set up a single–carrier NADC digital modulation with customized
modulation type, symbol rate, and filtering.
Figure 13-18 Setting a Digital Modulation Filter
This softkey label updates to reflect
the current modulation standard.
Mode > ARB Custom Modulation > Single Carrier Setup
page 343
This softkey
sets the filter
bandwidth
parameter,
alpha. The
default Alpha
value changes
with the
modulation
standard (see
page 353) and
modulation
type selected
(see
page 319).
For details on each key, use key help as described on page 44.
This softkey sets
the filter shape.
page 340
Opens a menu to select a
IS-95 filter.
