Alcatel-Lucent 7210 SAS M Service Guide

Configuring a VPLS Service with CLI
Page 338 7210 SAS M Services Guide
Configuring Load Balancing with Management VPLS
With the concept of management VPLS, it is possible to load balance the user VPLS services
across the two protecting nodes. This is done by creating two management VPLS instances, where
both instances have different active spokes (by changing the STP path-cost). When different user
VPLS services are associated with either the two management VPLS services, the traffic will be
split across the two spokes.
Load balancing can be achieved in both the SAP protection and spoke SDP protection scenarios.
Figure 53: Example Configuration for Loadbalancing Across Two Protected VPLS Spoke SDPs
GRAPHIC TBD
OSSG330
Dut - B
7x50
Dut-C
7x50
S
S
Dut-A
7210
SAS-M
S
S
S
S
S
SSS SS
SDP 2301
SDP 2302
SDP 1201 SDP 1202
SDP 1401SDP 1402
Path Cost
100
Path Cost
100
mvpls 100
MVPLS M1
Dut-A Spoke SDP 1201:100 (STP blocked);
1401:100
Dut-B — Spoke SDP 1201:100; 2301:100
Dut-C — Spoke SDP 1401:100; 2301:100
uvpls 101
UVPLS U1
Dut-A — Spoke SDP 1201:101; 1401:101
Dut-B — Spoke SDP 1201:101; 2301:101
Dut-C — Spoke SDP 1401:101; 2301:101
mvpls 200
MVPLSM2
Dut-A — Spoke SDP 1202:200; 1402:200 (STP
blocked)
Dut-B — Spoke SDP 1202:200; 2302:200
Dut-C — Spoke SDP 1402:200; 2302:200
uvpls 201
UVPLS U2
Dut-A — Spoke SDP 1202:201; 1402:201
Dut-B — Spoke SDP 1202:201; 2302:201
Dut-C — Spoke SDP 1402:201; 2302:201
