Layout and function
36
GreenDrill BAH0054-9 11.17
4.1.4 Calibration test
For calibration and when emptying the seed
hopper, the seed drops into the collection bag (2)
over the chute (1).
Always perform a calibration test
during the initial operation.
when changing the sort.
if the same sort is used, but of a different quality and specific weight.
after changing the seed metering wheels
if the seed hopper is emptied faster/slower than expected. The actual spread rate then does not
correspond with the spread rate determined by calibration.
when changing the working speed (not required with terminal 5.2 and connection to the 7-pin sig-
nal socket of the tractor or the radar or GPS device).
4.2 Agitator shaft
When seeding spelt-type and very light seeds,
e.g. grasses, the rotating agitator shaft (1) pre-
vents faulty seeding caused by seed blockage in
the seed hopper.
With seeds that flow down well, rotation of the
agitator shaft is not necessary.
