GreenDrill control terminal 5.2
98
GreenDrill BAH0054-9 11.17
7.19.2 Implement cable connection diagram for implements with hydraulic blower
fan
Implement cable
signal socket
6-pin
Cable
seeding shaft
motor
Cable
low level sensor
Cable
seed calibra-
tion button
Cable
pressure
sensor
blower fan
Cable
blower fan
speed
sensor
PIN cable
1
Blue
4 mm²
A
Black 1.5
mm²
B
Brown
0.75 mm²
C
Brown
0.75 mm²
2
Brown
4 mm²
3
Blue
1.5 mm²
D
Red
1.5
mm²
4
Grey
1.5 mm²
E
Blue
0.75 mm²
F
Brown
0.75 mm²
G
Blue
1.5 mm²
H
Blue
0.75 mm²
5
Brown
1.5 mm²
I
White
0.75 mm²
6
Black
1.5 mm²
J
Black
0.75 mm²
