GreenDrill control terminal 3.2
GreenDrill BAH0054-9 11.17
57
6.8 Turning at end of the field
1. Press the button.
The green control lamp above the button is turned off
The seeding shaft stops
The blower fan continues to run.
2. Lift the carrying implement, turn, and move back to working position.
3. Start driving and press the
button.
The green control lamp above the button is illuminated.
The seeding shaft rotates at the nominal speed.
The seed is metered.
6.9 Emptying the seed hopper
1. Prepare the implement for emptying the seed hopper (see section 5.6, page 46).
2. Switch on the control terminal.
3. Do not switch on the blower fan.
4. Press the button, hold it and press the button.
The seeding shaft rotates at maximum speed.
5. Press the
button
as soon as the seed hopper is empty and the seed metering wheels no longer convey seed.
The seeding shaft stops.
The seeding shaft drive can be switched off
at any time by pressing the
button.
