7.20.6 Signal sources
The control terminal 5.2 requires several signals. The signals are provided either by 7-pin tractor sig-
nal socket or the signals come from other sources. The source must be named in the control terminal.
Forward speed signal source [km/h]
The following sources can, if equipped, deliver the "Forward speed [km/h]" signal:
 The actual signal
is delivered to PIN 1 of the 7-pin tractor signal socket.
 The theoretical signal
is delivered to PIN 2 of the 7-pin tractor signal socket.
The signal comes from e.g. a gearbox sensor or a different source.
Note: If possible, use the more precise signal from PIN 1.
 The signal comes from a radar device (see page 95) that is connected to the control terminal
through a splitter.
 The signal comes from a GPS device (see page 96) that is connected to the control terminal
through a splitter.
Working/transport position signal source
The "working/transport position" signals show the position of the GreenDrill:
 Working position or
 Transport position.
The following sources can, if equipped, deliver the signals:
 The signals are delivered by the 7-pin tractor signal socket
 The signals come from a working position (see page 94) that is connected to the control terminal
through a splitter.
