GreenDrill control terminal 5.2
GreenDrill BAH0054-9 11.17
97
7.19 Implement cable connection diagram
7.19.1 Implement cable connection diagram for implements with electric blower fan
Implement cable
signal socket
6-pin
Cable
blower fan mo-
tor
Cable
seeding shaft
motor
Cable
low level sen-
sor
Cable
seed calibra-
tion button
PIN cable
1
Blue
4 mm²
A
Blue
4 mm²
B
Black 1.5
mm²
C
Brown
0.75 mm²
2
Brown
4 mm²
D
Brown
4 mm²
3
Blue
1.5 mm²
E
Red
1.5
mm²
4
Grey
1.5 mm²
F
Blue
0.75 mm²
G
Brown
0.75 mm²
5
Brown
1.5 mm²
H
White
0.75 mm²
6
Black
1.5 mm²
I
Black
0.75 mm²
