Settings before commissioning
44
GreenDrill BAH0054-9 11.17
5.3 Replacing the seeding shaft
1. Switch off the control terminal.
2. Empty the seed hopper.
3. Remove the protective cover (1).
3.1 Loosen and remove the 2 hexagonal
nuts (2) with the socket wrench (3).
4. Remove the round belt (1).
5. Release the knurled nuts (2).
6. Remove the cover and pull out the seeding
shaft (1).
7. Refer to the seeding table for the required
seed metering wheels (see section 9,
page 107).
The seeding shaft is installed in the reverse se-
quence.
The existing seeding shaft can be
reinstalled after converting the seed
metering wheels. It is more conven-
ient to install a second seeding shaft
that is already equipped with the re-
quired seed metering wheels.
