User Manual – Rev BE AMETEK Programmable Power
MX Series 25
Multiple Cabinet Systems
Output
Parameter
MX6 0
MX9 0
MX135
MX180
MX225
MX270
Line Regulation: 0.1% for 10% input line change
DC Off s e t Vol t a g e : < 20 mV
Output Noise:
(20 kHz to 1 MHz)
< 2 VRMS l o w V Ra n g e
< 3 VRMS high V Range
Output Coupling
DC coupled
Except on optional -HV o r -XV Voltage range output, which is AC coupled.
Power (total power for all phases, either range, at full scale voltage, maximum ambient T = 35° C)
AC Mo d e 60 KVA 90 KVA 135 KVA 180 KVA 225 KVA 270 KVA
DC Mo d e 40 KVA 60 KW 90 KW 120 KW 150 KW 180 KW
AC+DC Mod e
The maximum power and current in the AC+DC mode are equal to that in the DC mode
Current
NOTE: Current, maximum amps indicated per phase available between 50 and 100 % of voltage range. Maximum ambient temperate for full power
operation at full-scale voltage is 35° C.
Constant Power Mode:
Operation at higher currents but constant power is possible from 80% of Voltage range (125% of max. current) declining to 100% of
maximum current at 100 % of voltage range for short periods of time or at reduced ambient temperatures. (< 15 mins @ 30° C). See Figu r e
2-1. (Requires firmware revision 0.27 or higher.)
Not e: Fo r MX60-3Pi model, constant power mode is supported at max ambient temperature.
AC Mo d e
Standard Models
per phase
V Lo : 133 A
V Hi : 66.7 A
per phase
V Lo : 200 A
V Hi : 100 A
per phase
V Lo : 300 A
V Hi : 150 A
per phase
V Lo : 400 A
V Hi : 200 A
per phase
V Lo : 50 0 A
V Hi : 250 A
per phase
V Lo : 60 0 A
V Hi : 300 A
AC Mo d e
-333 Op t i on
per phase
V Lo : 120 A
V Hi : 60 A
per phase
V Lo : 180.2 A
V Hi : 90.1 A
per phase
V Lo : 270.3 A
V Hi : 135 A
per phase
V Lo : 360.3 A
V Hi : 181.2 A
per phase
V Lo : 450 A
V Hi : 225 A
per phase
V Lo : 540.6 A
V Hi : 270.3 A
DC Mo d e / AC+ DC
Mo d e
Standard Models
per phase
V Lo : 66.7 A
V Hi : 33.3 A
per phase
V Lo : 100 A
V Hi : 50 A
per phase
V Lo : 150 A
V Hi : 75 A
per phase
V Lo : 200 A
V Hi : 100 A
per phase
V Lo : 250 A
V Hi : 125 A
per phase
V Lo : 300 A
V Hi : 150 A
DC Mo d e / AC+ DC
Mo d e
-333 Op t i on
per phase
V Lo : 60.6 A
V Hi : 30.2 A
per phase
V Lo : 90.9 A
V Hi : 45.4 A
per phase
V Lo : 136.3 A
V Hi : 68.1 A
per phase
V Lo : 181.8 A
V Hi : 90.9 A
per phase
V Lo : 227.2 A
V Hi : 113.6 A
per phase
V Lo : 272.7 A
V Hi : 136.3 A
NOTE: Current derates linearly from 50% of voltage range to 20% of specified current at 5% of voltage range
Current Limit mode P r o g r a m m a b l e , CC o r CV m o d e
Repetitive Peak Current
NOTE: Maximum Peak Current shown. Value shown reflects absolute peak current protection level. This level may not be reached under all load
conditions. Depending on load conditions, peak current may max out at lower levels due to amplifier output impedance.
NOTE: As of firmware revision 4.52, a repetitive peak current limit function is provided which will generate a fault and shut off the power supply if
the peak current drawn by the load exceeds the maximum level for more than 30 seconds. During this time, the amplifier will limit the peak
current at a level somewhat above the maximum level, but it is not allowable to run in this mode indefinitely. This should provide sufficient
time to ride through any startup/ inrush load conditions.
AC Mo d e
Standard Models
per phase
V Lo : 600 A
V Hi : 300 A
per phase
V Lo : 600 A
V Hi : 300 A
per phase
V Lo : 900 A
V Hi : 450 A
per phase
V Lo : 1200 A
V Hi : 600 A
per phase
V Lo : 1500 A
V Hi : 750 A
per phase
V Lo : 1800 A
V Hi : 900 A
AC Mo d e
-333 Op t i on
per phase
V Lo : 540 A
V Hi : 282 A
per phase
V Lo : 540 A
V Hi : 270 A
per phase
V Lo : 810 A
V Hi : 405 A
per phase
V Lo : 1080 A
V Hi : 540 A
per phase
V Lo : 1350 A
V Hi : 675
per phase
V Lo : 1621 A
V Hi : 810 A
Frequency
Range:
Standard: 16 Hz - 819.0 Hz (for –HV option range, 45 Hz – 819.0 Hz)
-LF option: 16 Hz - 500.0 Hz
-HF option: 16 Hz – 905 Hz
Resolution:
0.01 Hz from 16.00 to 81.91 Hz
0.1 Hz from 82.0 to 819.0 Hz
Accuracy: ± 0.01 %
