Chapter 3 Software Navigation
Part Number: 0160-6411, Rev A, 02/2019 Page 111 of 314
Software Release: cOS 5.00
From the Cataract Incisions Sideport(s) Geometric Details Screen, you can select the following
parameters:
• Uncut Region (Anterior, Central, Posterior, or None)
• Depth Unit (Percent or Microns)
• Uncut Anterior/Posterior Percentage or Microns
• Uncut Central Length
• Anterior/Posterior Plane Depth
• Anterior/Posterior Side Cut Angle
Once you have chosen valid settings, the anterior and posterior side cut angles and uncut region
are displayed in the lower eye model, as shown in the preceding figure. Press the button to
go to Cataract Incisions Primary Laser Details Screen, the button to go to the Cataract
Incisions Primary Geometric Details Screen, the BASIC button to return to the Cataract Incisions
(Basic) Screen, the BACK button to return to the (Basic) Screen for the previous procedure in the
sequence, or the NEXT button to proceed to the Treatment Plan Summary Screen.
NOTES
If you selected only the cataract incisions procedure on the Plan a Treatment Screen, pressing the
BACK button on any of the Cataract Incisions Details Screens will take you back to the Plan a
Treatment Screen.
If you press the HOME button on any of the Cataract Incisions Details Screens, the current
treatment parameters will be saved.
