Appendix A – Chapter 2 Mobile Patient Bed Operation
Page 258 of 314 Part Number: 0160-6411, Rev A, 02/2019
Software Release: cOS 5.00
1. Place the bed in the lowest position.
2. Place the control pendant in the holster.
3. Ensure that the AC power cord is disconnected from the wall outlet, if applicable.
4. Unlock the casters, as described in Locking/Unlocking the Casters on page 255.
5. If desired, activate directional lock mode, as described in Activating/Deactivating
Directional Lock Mode on page 256.
6. Move the bed to the desired location.
CAUTION
Do not push or pull the Mobile Patient Bed using the headrest or headrest assembly. Applying
excessive pressure to the headrest or headrest assembly may damage these components.
2.5 Positioning the Bed Next to the CATALYS® System
The Mobile Patient Bed should be placed next to the CATALYS® System to accommodate the
following three bed positions:
• Patient load position–The bed is rotated approximately 50° out from under the CATALYS®
System. This position allows for patient loading and unloading and provides clearance for
the bed to be in the upright seated or flat position.
• LIQUID OPTICS™ Interface installation position–The bed is rotated approximately 19° out
from under the CATALYS® System. This position allows the physician convenient access to
the treatment eye for LIQUID OPTICS™ Interface installation.
• Patient treatment position–The bed is rotated to the 0° position under the CATALYS®
System with the patient treatment eye located directly under the laser aperture. This
position allows the physician to dock the patient to the CATALYS® System and perform
Cataract Laser Surgery.
2.6 Connecting the Bed to the CATALYS® System
Refer to Connecting the Mobile Patient Bed to the CATALYS® System on page 181 for instructions
on connecting the bed to the CATALYS® System.
The (connect) button on the control pendant indicates the connection status, as follows:
• Slowly blinking blue—Mobile Patient Bed is attempting to connect to CATALYS® System
• Solid blue—Mobile Patient Bed is connected to CATALYS® System
• Rapidly blinking blue—Mobile Patient Bed has been disconnected from CATALYS® System
during procedure
The (Bluetooth connection status) icon on the CATALYS® System touchscreen also indicates
the connection status, as follows:
• Solid blue—Mobile Patient Bed is connected to CATALYS® System
