Chapter 4 CATALYS® System Procedure
Part Number: 0160-6411, Rev A, 02/2019 Page 167 of 314
Software Release: cOS 5.00
Arcuate and Cataract Incision Parameters
Figure 4.6 Arcuate Incision Characteristics
Frontal view of arcuate incisions. Optical zone is user‐adjustable. For asymmetric arcuate
incisions, the optical zone is independently adjustable for each incision. Arc length is also
user‐adjustable.
Axis
Optical Zone
Optical Zone
Length
Limbus
Pupil
