Appendix A – Chapter 2 Mobile Patient Bed Operation
Page 252 of 314 Part Number: 0160-6411, Rev A, 02/2019
Software Release: cOS 5.00
1. Pull out the neck support locking lever to unlock the neck support.
2. Adjust the neck support as desired.
3. Push the lever flush with the headrest to lock the neck support.
Figure 2.4 Location of Neck Support and Locking Lever
Head Clamp Adjustment
The head clamp is adjustable by pulling apart or pushing together both sides of the head clamp.
The amount of force required to adjust the head clamp is also adjustable using the head clamp
tension control.
Move the tension control to the left to loosen the tension (i.e., reduce the amount of force
required to adjust the head clamp); move the tension control to the right to tighten the tension
(i.e., increase the amount of force required to adjust the head clamp).
Figure 2.5 Location of Head Clamp and Tension Control
Neck support
Neck support
locking lever
Head clamp
tension control
Head clamp
To Next Page
