Appendix B – Patient Chair Instructions
Part Number: 0160-6411, Rev A, 02/2019 Page 293 of 314
Software Release: cOS 5.00
Patient Chair Specifications
* OPTIMEDICA reserves the right to make changes to the device(s) herein. Device(s), therefore, may not
agree in detail with the published design or specifications. All specifications are subject to change with‐
out notice. Contact OPTIMEDICA or your local OPTIMEDICA representative for information on changes
and new products.
Patient Chair Installation and Setup
The Patient Chair is designed for installation and use inside a sterile operating room or in a non-
sterile pre-op area within an ambulatory surgery center (ASC) or a hospital. Initial installation
and testing will be performed by OPTIMEDICA-certified personnel.
During normal use, the Patient Chair operates on electrical power supplied by the CATALYS®
system.
Environmental Requirements (Operating)
Maximum altitude 7,000 ft (2,134 m)
Temperature range 59 – 89.6 °F (15 – 32 °C)
Maximum humidity Up to 80% @ 89.6 °F (32 °C) non-condensing
Operating environment
Temperature controlled environment with temperature controlled to
within ±3.6 °F (±2 °C)
Atmospheric pressure No atmospheric pressure dependency during the operation of the device.
Environmental Requirements (Non-operating)
Maximum altitude Standard commercial shipping altitude
Temperature range 32 – 131°F (0 – 55°C)
Maximum Humidity Up to 80% @ 55°C, non-condensing
Physical Characteristics
Length 70.5 in (1.79 m)
Back Width 26.75 in(.68 m)
Seat Width 21.25 in (.54 m)
Chair height
Lowest position: 22 in (56 cm)
Highest position: 26 in (66 cm)
Weight 480 lb (218 kg)
Maximum patient weight 500 lb (227 kg)
Safe Working Load 534 lb (242 kg)
Articulation Range
Backrest inclination 0° to 75°
Swivel range (lockable) 25° right and left from center
Classifications
IEC 60601-1 protection against
electric shock
Type B
IEC 60601-1 patient leakage Footrest, seat, backrest, headrest, armrests
