Lens Fragmentation Parameters
Lens Fragmentation parameters, including cut dimensions for lens segmentation and softening,
laser settings, and applicable safety margins, are illustrated in the following figures and
summarized in the following tables.
Patterns Description
Lens Segmentation: Quadrants
(2 intersecting lines)
Lens Segmentation: Sextants
(3 intersecting lines)
Lens Segmentation: Octants
(4 intersecting lines)
Lens Softening: Quadrants
Lens Softening: Sextants
Lens Softening: Octants
Quadrants Complete
