NOTE
The EMISSIONS characteristics of this equipment make it suitable for use in industrial areas and
hospitals (CISPR 11 class A). If it is used in a residential environment (for which CISPR 11 class B is
normally required) this equipment might not offer adequate protection to radio‐frequency
communication services. The user might need to take mitigation measures, such as relocating or
re‐orienting the equipment.
Table 5.2 Guidance and Manufacturer's Declaration: Electromagnetic Immunity
(This table applies to IEC60601-1-2, 3rd Edition compliant CATALYS® manufactured prior to January 1st, 2019)
The CATALYS® System is intended for use in the electromagnetic environment specified below. The customer or
the user of the CATALYS® System should ensure that it is used in such an environment.
NOTE: Ut is the a.c. mains voltage prior to application of the test level.
Immunity Test IEC 60601 Test Level Compliance Level
Electromagnetic Environment:
Guidance
Electrostatic Dis-
charge (ESD)
IEC 61000-4-2
±6 kV contact
±8 kV air
±2, 4, 6 kV contact
±2, 4, 8 kV air
Floors should be wood, concrete, or
ceramic tile. If floors are covered
with synthetic material, the relative
humidity should be at least 30%.
Electrical fast tran-
sient/ burst
IEC 61000-4-4
±2 kV for power supply
lines
±1 kV for input/output
lines
±2 kV line to ground
±1 kV line to line
Mains power quality should be that
of a typical commercial or hospital
environment.
Surge
IEC 61000-4-5
±1 kV Differential mode
±2 kV common mode
±0.5,1 kV
differential mode
±0.5,1,2 kV
common mode
Mains power quality should be that
of a typical commercial or hospital
environment.
Voltage dips, short
interruptions, and
voltage variations
on power supply
input lines
IEC 61000-4-11
<5% Ut (>95% dip in Ut)
for 0.5 cycle
40% Ut (60% dip in Ut)
for 5 cycles
70% Ut (30% dip in Ut)
for 25 cycles
<5% Ut (>95% dip in Ut)
for 5 sec.
<5% Ut (>95% dip in Ut)
for 0.5 cycle
40% Ut (60% dip in Ut) for
5 cycles
70% Ut (30% dip in Ut) for
25 cycles
<5% Ut (>95% dip in Ut)
for 5 sec.
Mains power quality should be that
of a typical commercial or hospital
environment. If the user of the
CATALYS® System requires contin-
ued operation during power mains
interruptions, it is recommended
that the CATALYS® System be pow-
ered from an uninterruptible power
supply or a battery.
Power frequency
(50/60Hz)
magnetic field
IEC 61000-4-8
3 A/m N/A
Power-frequency magnetic fields
should be at levels characteristic of
a typical location in a typical com-
mercial or hospital environment.
To Next Page
