Appendix B – Patient Chair Instructions
Page 288 of 314 Part Number: 0160-6411, Rev A, 02/2019
Software Release: cOS 5.00
Introduction
In addition to the Mobile Patient Bed, there are two custom patient chairs available for use with
the CATALYS® System: one manufactured before May 2013 and another manufactured after
May 2013. The following instructions pertain to both patient chairs, except where noted.
Figure B.1 Patient Chair Components
Headrest assembly
Joystick control
Joystick Cable connection to chair –
red dot on plug and receptacle to be
in 12 o'clock position
Headrest Vertical
Adjustment Knob
Joystick operation label
To Next Page
