15 – 51

SHIFTER

ARITHMETIC SHIFT

Instruction Format:

Conditional Shift Operation, Instruction Type 16:

23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

0 0 0 0 1 1 1 0 0 SF Xop 0 0 0 0 COND

SF Shifter Function

0 1 0 0 ASHIFT (HI)

0 1 0 1 ASHIFT (HI, OR)

0 1 1 0 ASHIFT (LO)

0 1 1 1 ASHIFT (LO, OR)

Xop: shifter operand COND: condition
