15
15 – 53
SHIFTER
LOGICAL SHIFT
Instruction Format:
Conditional Shift Operation, Instruction Type 16:
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 0 1 1 1 0 0 SF Xop 0 0 0 0 COND
SF Shifter Function
0 0 0 0 LSHIFT (HI)
0 0 0 1 LSHIFT (HI, OR)
0 0 1 0 LSHIFT (LO)
0 0 1 1 LSHIFT (LO, OR)
Xop: shifter operand COND: condition
