The AR saturation mode bit, (AR_SAT), when set to 1, causes the AR
register to saturate if an ALU operation causes an overflow, as described
in Chapter 2, “Computation Units.”
The MAC result placement mode (M_MODE) determines whether or not
the left shift is made between the multiplier product and the MR register.
Setting the Timer Enable bit (TIMER) starts the timer decrementing logic.
Clearing it halts the timer.
The GO mode (G_MODE) allows an ADSP-21xx processor to continue
executing instructions from internal memory (if possible) during a bus
grant. The GO mode allows the processor to run; only if an external
memory access is required does the processor halt, waiting for the bus to
be released.
Instruction Format:
Mode Control, Instruction Type 18:
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 0 1 1 0 0 TI MM AS OL BR SR GM 0 0
TI: Timer Enable MM: Multiplier Placement
AS: AR Saturation Mode Control OL: ALU Overflow Latch Mode
BR: Bit Reverse Mode Control Control
GM: GO Mode SR: Secondary Register Bank
Mode
