Analog Devices adsp-2100 User Manual

A Instruction Coding
A – 14
YY see YY, CC, BO below
Z ALU/MAC Result Register codes
0 Result register
1 Feedback register
YY, CC, BO ALU / MAC Constant codes (Type 9)
(ADSP-217x, ADSP-218x, ADSP-21msp58/59 only)
Constant (hex) YY CC BO Bit #
0001 00 00 01 bit 0
0002 00 01 01 bit 1
0004 00 10 01 bit 2
0008 00 11 01 bit 3
0010 01 00 01 bit 4
0020 01 01 01 bit 5
0040 01 10 01 bit 6
0080 01 11 01 bit 7
0100 10 00 01 bit 8
0200 10 01 01 bit 9
0400 10 10 01 bit 10
0800 10 11 01 bit 11
1000 11 00 01 bit 12
2000 11 01 01 bit 13
4000 11 10 01 bit 14
8000 11 11 01 bit 15
FFFE 00 00 11 ! bit 0
FFFD 00 01 11 ! bit 1
FFFB 00 10 11 ! bit 2
FFF7 00 11 11 ! bit 3
FFEF 01 00 11 ! bit 4
FFDF 01 01 11 ! bit 5
FFBF 01 10 11 ! bit 6
FF7F 01 11 11 ! bit 7
FEFF 10 00 11 ! bit 8
FDFF 10 01 11 ! bit 9
FBFF 10 10 11 ! bit 10
F7FF 10 11 11 ! bit 11
EFFF 11 00 11 ! bit 12
DFFF 11 01 11 ! bit 13
BFFF 11 10 11 ! bit 14
7FFF 11 11 11 ! bit 15
