Analog Devices adsp-2100 User Manual

E Control/Status Registers
E – 10
Memory-Mapped Registers
DM(0x3FE6)
HSR6 Status Register
0000000000000000
0123456789101112131415
21xx HDR0 Write
21xx HDR1 Write
21xx HDR2 Write
21xx HDR3 Write
21xx HDR4 Write
21xx HDR5 Write
Host HDR0 Write
Host HDR1 Write
Host HDR2 Write
Host HDR3 Write
Host HDR4 Write
Host HDR5 Write
(ADSP-2171, ADSP-2111,
ADSP-21msp5x only)
151413121110987654 32 10
HDR5
HIP Data Registers
DM(0x3FE5)
15141312111098765432 10
HDR4
DM(0x3FE4)
15141312111098765432 10
HDR3
DM(0x3FE3)
151413121110987654 32 10
HDR2
DM(0x3FE2)
15141312111098765432 10
HDR1
DM(0x3FE1)
151413121110987654 32 10
HDR0
DM(0x3FE0)
(ADSP-2171, ADSP-2111,
ADSP-21msp5x only)
